What are the size range for heavy duty drawer slides

一. The main specifications of heavy duty drawer slides as follow:

 1. 51 mm wide heavy duty drawer slides

 The width of this drawer slides is 51 mm and the material thickness is 1.5×1.5×1.5 mm. Its installation clearance is 12.7 mm, and its load-bearing capacity can reach 75 KG.

  2. 53 mm wide heavy duty drawer slides

  Compared with the 51 mm wide drawer slides, the width gap of the 53 mm wide slide rail has increased to 53 mm. Its material thickness is 2.0×2.0×2.0 mm, and the installation gap is 19 mm. Due to its thickened material, the load-bearing capacity of the 53-wide heavy-duty slide rail reaches 150 KG.

 3.  76 mm wide heavy duty drawer slides

  As the widest heavy-duty slide rail, its width reaches 76 mm. The material thickness is 2.5×2.5×2.5 mm, and the installation gap is 19.3 mm. The load-bearing capacity of this slide rail basically reaches 250 KG.

 二. Specifications, characteristics and selection

  Heavy duty drawer slides of different specifications each have their own characteristics and application areas. The 51 mm wide drawer slides is suitable for occasions that need to withstand greater pressure and suitable size; the 53 mm wide drawer slides is suitable for occasions that need to withstand greater pressure but does not have high size requirements; and the 76 mm wide drawer slides has enhanced load-bearing capacity and increased Large size, suitable for occasions that need to withstand great force.

 三. In conclusion

   When selecting heavy duty drawer slides, you need to consider based on actual needs and conditions. For example, for the slide faster and are easier to operate should be selected; for occasions that need to withstand greater pressure, slide rails with strong load bearing capacity and high stability should be selected. At the same time, factors such as the material, wear resistance, and abrasion resistance of the slide rail must also be considered.
